Appendices
85
No. Code
Bearing
Code
Bearing Name Assembly Position Quantity
Lower End of the Front
Final Drive Shell
2
19 688711 Release Bearing
Release Bearing of the
Clutch
1
20 GB/T 5,846 K202,417 Needle Bearing
Intermediate Shaft of the
Transfer Case
2
21 GB/T 5,846 K25,3120 Needle Bearing
Output Shaft of the
Transfer Case
2
22 GB/T 5,846 K283,327 Needle Bearing Driven Gear of Gear 2
23 GB/T 5,846 K303,527 Needle Bearing H-L Stationary Gear 2
24 GB/T 292 7,206AC
Angular Contact
Ball Bearing
Inner End of the Front
Drive Shaft
2
25 GB/T 292 7,208AC
Angular Contact
Ball Bearing
Outer End of the Front
Drive Shaft
2
26 GB/T 297 32007
Cylindrical Roller
Bearing
Middle of the Mater Pinion
Shaft
1
27 GB/T 297 32010
Cylindrical Roller
Bearing
Front Axle Differential
Shell
2
28 GB/T 297 32207
Cylindrical Roller
Bearing
Front of the Mater Pinion
Shaft
1
Driving Gear of Gearbox 1
29 GB/T 5,846 K424,822 Needle Bearing
Driving Gear of Gearbox 1
