4-15
Security 15088:K 03/21/01
Zone Programming (continued)
ÕÖÕÖ
ÕÖÕÖ
ÕÖ
For-
ward
Zones
Reverse
Zones
Zone Boundary greater than or equal to Z22 and less than Z180.
ÕÕ
ÕÕ
Õ
ÖÖ
ÖÖ
Ö
Notification Appliance with a Control Module
When using an optional control module for Notification Appliances intended to indicate a security violation, this
control module may be programmed with the following Control-By-Event equation:
AND(Zab* SDEL(00.00.00 00.15.00 (Zaj*)))
resulting in 15 minutes of Notification Appliance activation after a security violation.
*Zaa through Zaj are each unique installer-specified zone numbers. Zaa is the lowest specified zone number (high-
est priority) and Zaj is the highest specified zone number (lowest priority).
Example:
Zaa Zab Zac Zad Zae Zaf Zag Zah Zai Zaj
Z5 Z12 Z22 Z180 Z188 Z199 Z200 Z210 Z211 Z212
10. Zone Active a Minimum of 30 Sec. if Entry/Exit
Delay Is Violated (Entry/Exit Door Only) When
System Is Armed
Zone: Zai*
Type ID: RZON
Control-By-Event:
AND(Zab* SDEL(00.00.00 00.00.30 (Zah*)))
Custom Label: Installer Specified.
Annunciator: No (Not required).
11. Zone Active at Least 30 Sec. for Any Security
Breach While System Is Armed
Zone: Zaj*
Type ID: RZON
Control-By-Event: OR(Zad* Zah* Zai*)
Custom Label: Installer Specified.
Annunciator: No (Not required).
8. Zone Active 1.5 Min. After Arming System
Zone: Zag*
Type ID: RZON
Control-By-Event: DEL(00.01.30 (Zab*))
Custom Label: Installer Specified.
Annunciator: No (Not required).
9. Zone Providing 30 Sec. Entry/Exit Delay (En-
try/Exit Door Only) When System Is Armed
Zone: Zah*
Type ID: RZON
Control-By-Event:
OR(AND(Zab* Zag* Zae*) AND(Zab* Zaf*))
Custom Label: Installer Specified.
Annunciator: No (Not required).
®®®®
®®®®
®®
causes Zone Zah* to
activate if entry/exit
time is exceeded.
causes Zone
Zah* to activate
if entry/exit door
is left open.
Programming Key for Figure 1.3-6 (Cont)
To Next Page
