Notifier AFP1010 User Manual

4-24
Security 15088:K 03/21/01
2. Zone to Which All Instant Security Modules
Are Mapped
Zone: Zaa*
Type ID: FZON
Control-By-Event: ( )
Custom Label: Instant Group
Annunciator: No (Not Required).
3. Zone Activated Upon Arming System
Zone: Zab*
Type ID: FZON
Control-By-Event: ( )
Custom Label: Arming Zone
Annunciator: Yes
Annunciator Point: ArrP1
4. Zone Activated When Entry/Exit Door Is
Open
Zone: Zac*
Type ID: FZON
Control-By-Event: ( )
Custom Label: Tenant A Entry/Exit
Annunciator: No (Not required).
5. Zone Activated When Any Instant Module Is Vi-
olated and the System Is Armed
Zone: Zad*
Type ID: RZON
Control-By-Event: AND(Zaa* Zab*)
Custom Label: Installer Specified.
Annunciator: No (Not required).
6. Zone Active for 30 Sec., 30 Sec. After Opening
Entry/Exit Door (Not Dependent on Door Clo-
sure)
Zone: Zae*
Type ID: RZON
Control-By-Event: SDEL(00.00.30 00.00.30 (Zac*))
Custom Label: Installer Specified.
Annunciator: No (Not required).
7. Zone Active 1 Min. After Entry/Exit Door Is
Opened and Left Open
Zone: Zaf*
Type ID: RZON
Control-By-Event: DEL(00.01.00 (Zac*))
Custom Label: Installer Specified.
Annunciator: No (Not required).
Protected Premises Unit (Slave)
Group Interface MM
Annunciator Point: AssPp**
Type ID: AMON
NIB-96
NIB-96 Network Interface Board (continued)
Point
p**
Central Station (Master)
Monitor Module Point (PPU Security Alarm
Input)
Address: LXXMYY
Type ID: SARM
Control-By-Event: (Installer Specified)
Custom Label: Installer Specified.
Tracking: Yes - Security alarm
conditions will restore automat-
ically at the Central Station af-
ter restoral at the Protected
Premises.
No - Security alarm conditions
will latch in the Central Station
until reset at the Central Station
and the Protected Premises
Unit if the NIB-96 has been
configured to prevent reset
from the Central Station - short
condition only.
Annunciator: No (Not required).
**Indicates installer-specified NIB point.
PPU Zone Programming
1. Zone Boundary: Must be less than Zad* and greater than or equal to Zac*.
Figure 1.3-10 Programming Key (continued):
