NFN Web Server User’s Manual PN 51990:A2 12/02/0310
NFN WEB SERVER DIALUP CONNECTION
The NFN Web Server can use a serial modem to communicate with a remote browser via telephone lines.
NWS
NCM-W/F
supplied by
customer
PC Browser
Interface
NOTI•FIRE•NET™ network
Figure 1-7.2: NFN Web Server PPP Architecture
NOTES: Only one user can dial into the server at a time.
The server can support an intranet/internet connection
simultaneously with a dialup connection.
!
modem
