NFN Web Server User’s Manual PN 51990:A2 12/02/03 13
SECTION TWO: NFN WEB SERVER HARDWARE INSTALLATION
2.1 R
EQUIRED COMPONENTS
The NFN Web Server requires the following equipment:
NFN Web Server Assembly:
• PC board (P/N 46173) for the NFN Web Server
• Power supply (P/N 46175) - 24VDC to 5VDC
• PNET-1 surge suppressor
• CAT5 cable (P/N 75585) - provides Ethernet connection cable between NFN Web Server PC board and PNET-
1 surge suppressor
• DB9 to NUP Cable (P/N 75554) - connects the NFN Web Server to an NCM-W/F
• Modem cable - connects the Web Server to a modem (see Figure 2.7-1)
• NUP to 24V power cable (P/N 75583) - provides power for the NCM-W/F (not required for standalone mode)
• HDD Power connector (P/N 75581) - used for 24VDC to 5VDC power connection
• Serial Configuration Tool software (supplied on CD-ROM, P/N NWS-SW)
• NFN Web Server/Power Supply Mounting Plate (P/N 18541)
Network Interface (sold separately):
• NCM-W/F Network Communications Module - used to facilitate network communication between the NFN
Web Server and NOTI•FIRE•NET™. NOTE: The NCM-W/F is not required when directly connecting an
NFN Web Server to an NFS-640 or NFS-3030 when either acts as a standalone panel.
Cabinetry/Installation Hardware (sold separately):
• CAB-3/CAB-4 series cabinet
• CHS-4L chassis
Other Required Equipment (NOTE: These items must be supplied by the customer.):
• PC to PC connector cable - connects the NFN Web Server to a PC or laptop.
• PC or notebook - used to configure the NFN Web Server.
NOTE: The NWS is for ancillary use only and
does not increase the burglary grade of service
for the system.
!
