18
Running Glucose a Test
1. Wash hands with soap and warm water then dry thoroughly. Or
use alcohol pads to clean area; dry thoroughly after cleaning.
NOTE: Cleaning of the puncture site is important.
2. Insert a glucose test strip into the monitor. Glucose is a blue
strip. If monitor was o, the screen displays all segments for 2
seconds.
NOTE: If the strip is removed before you start the test, the screen
goes blank.
3. After 3 seconds, the blinking blood drop symbol appears with
“Glu” displaying.
NOTE: If a test is not performed within 2 minutes from the insertion
of the test strip, the screen goes blank. To perform a test, take out
then replace the test strip starting from Step 2.
4. Holding hand downward, massage nger with thumb toward
tip to stimulate blood ow.
Apply Blood
Drop Here
Insert this
End Into
Monitor
Nova Max Plus Monitor OG PN46171D1 EN.indd 18 9/5/12 3:22 PM
