Novation Launchpad Pro Programmer's Reference Guide

© Focusrite Audio Engineering LTD
26
Parameter Name
6th Byte
Value 1
Value 2
Value 3
Value 4
Repeatable?
Notes
Flash LED
23h
(35)
LED
01h - 63h
(1-99)
Colour
00h - 7Fh
(0-127)
--
--
Yes, up to 97
times
Selected LED flashes between current
lit colour and colour specified in value
2. If selected LED is not lit then it will
flash between off and the colour
specified in value 2.
Pulse LED
28h
(40)
LED
01h - 63h
(1-99)
Colour
00h - 7Fh
(0-127)
--
--
Yes, up to 97
times
Selected LED pulses with the colour
specified in value 2.
Scroll text across
pads
14h
(20)
Colour
00h - 7Fh
(0-127)
Loop
0 = loop off
1 = loop on
Text
--
No
Text can be standard ASCII characters
or plain values 1 - 7 to change speed
Mode selection
21h
(33)
Mode
(0-1)
--
--
--
No
00 = Ableton mode
01 = Standalone mode (default)
Mode status
2Dh
(45)
Mode
(0-1)
--
--
--
No
Status returned by Launchpad Pro
00 = Ableton mode
01 = Standalone mode
Live Layout
selection
22h
(34)
Layout
00h – 0Dh
(0-13)
--
--
--
No
For Ableton Live mode only.
00 = Session
01 = Drum Rack
02 = Chromatic Note
03 = User (Drum)
04 = Audio (Blank)
05 = Fader
06 = Record Arm (Session)
07 = Track Select (Session)
08 = Mute (Session)
09 = Solo (Session)
0A = Volume (Fader)
