Novitool Aero - Top Beam Installation and Bumper Use

—13—
Operation of the Aero
®
Press
g.
f.
Install top press beam:
a. Carefully position top press beam; align
grooves on end plates to avoid disrupting
or possibly separating ngers. Depending
upon width and weight of the press, you may
require assistance from another person.
b. Aero® 925-2135 presses are provided with a
roller slide xture to aid in sliding top press
beam over clamp bars, across the splice.
Ensure clamp bars are secured prior to using
roller slider. Put the roller slider against the
clamp bar bolts as the starting position and
position top beam end close to roller. Push
the top beam over until it is in close proximity
to the opposite end clamp bar studs. Li top
press beam at the opposite end and remove
roller slide xture. Aer splicing remove the
top beam in reverse order. Make sure the top
beam will not drop o the roller slider at the
end of the stroke.
A5
a.
b1.
b2.
f. WARNING: It is critical to use “bumpers”
(same belt material) to ll remaining splice
platen surface between the clamp bolts on
each end of press. is ensures even pressure
and temperature across splice width and
avoids overheating or damaging press.
g. Lay clean silicone pad (or other release
material) over prepared splice, using care to
avoid wrinkles in silicone pad.
