NSK Primado 2 User Manual

15
When Using the Foot Control
1) When depressing the Pedal of the Foot Control, the Motor starts to operate. When depressing the
Pedal or releasing it, a short alarm sounds.
2) In the Reverse Mode, the Bur starts rotating in reverse. During this reverse rotation, the alarm
continues to sound.
Trigger
Upper (A)
Lower (B)
Upper and Lower depressed simultaneously (A B)
Rotation Direction
Reverse Rotation
Forward Rotation
Oscillation (Forward and reverse rotations are repeated alternately)
Fig. 8

The Wire Pin Driver operates in the rotation direction set not by the Control Unit but by the Wire Pin Driver.
CAUTION
Pedal
