NSK Ti-Max Z Series User Manual

7
EN DE FR ES IT PT
6. Insertion & Removal of the Bur
6-1 To Insert the Bur (Fig. 3)
1) Insert the bur into the chuck.
2) Depress the Push Button to open the chuck ( ).
3) Fully insert the bur into the chuck until it stops ( ) then release the Push Button.
4) Ensure that the bur is secure by gently pulling and pushing the bur WITHOUT depressing the Push Button.
6-2 To Remove the Bur (Fig. 4)
Depress the Push Button to open the chuck ( ) and remove the bur ( ).
1
2
Fig. 3
1
2
Fig. 4
Push Button
Push Button
