Part 9 - Controls
4. User Menu - DHW Setup
Navigate the DHW Setup menu as follows:
1. From the User Menu select “DHW Setup” and press ENTER.
2. Press ENTER to select DHW Setpoint.
3. Turn the dial to modify the value and press ENTER to save it.
4. Press ESC to return to the previous screen.
User Menu
Screen Settings
Time & Date
CH Setup
DHW Setup
Operating Mode
DHW Setup
DHW Setpoint
124
Tank Setpoint (COMFORT)
124°F
Maximum value
Minimum value
140 °F
97 °F
Tank Setpoint (COMFORT)
130°F
Maximum value
Minimum value
140 °F
97 °F
User Menu
Screen Settings
Time & Date
CH Setup
DHW Setup
Operating Mode
DHW Setup
DHW Setpoint
124
Tank Setpoint (COMFORT)
124°F
Maximum value
Minimum value
140 °F
97 °F
Tank Setpoint (COMFORT)
130°F
Maximum value
Minimum value
140 °F
97 °F
Approximate Time / Temperature Relationships in Scalds
120
o
F More than 5 minutes
125
o
F 1 1/2 to 2 minutes
130
o
F About 30 seconds
135
o
F About 10 seconds
140
o
F Less than 5 seconds
145
o
F Less than 3 seconds
150
o
F About 1 1/2 seconds
155
o
F About 1 second
An ASSE 1017 or ASSE 1070 temperature limiting or mixing valve is recommended in installations
servicing disabled or elderly persons, or children. Mixing valves do not eliminate the risk of scalding.
To avoid scalding:
• Set the water heater set point temperature as low as possible.
• Feel water before bathing or showering.
• If thermostatic valves are required, use devices specifically designed for such purpose. Install
these devices in accordance with instructions provided by the manufacturer.
Failure to install a temperature limiting or mixing valve and follow these instructions could result in
property damage, severe personal injury, or death due to scalds.
WARNING
Note: pressing ESC will exit the setting without saving the new value.
Hotter water
increases the
risk of scald
injury. Scalding
may occur
within five (5)
seconds at a
setting of 140°F.
Water temperature over 125°F can
instantly cause severe burns or death
from scalds. Children, disabled, and
elderly persons are at the highest
risk of being scalded. See instruction
manual before setting temperature
at the appliance. Feel water before
bathing or showering.
DANGER
Figure 85 - User Menu
DHW Setup Menu
Table 30 - DHW Setup
Menu Option | Description (Range Default
DHW SETPOINT (2.0.0)
Combi Models
Establishes the target temperature of the DHW exiting the boiler. (97-140°F)
Non-Combi Models
establishes the target temperature of the DHW tank (IWH). Setting is only
applicable when DHW Mode is set to Tank Sensor. (104-149°F)
124°F
Table 31 - Approximate Time / Temp. Relationships
