TRX Series II - Installation - Startup - Maintenance Instructions
5. 7 ZONE 2 REGULATION PARAMETERS
5. 7. 5 Auto Slope Boost 0 = OFF, 1 = ON 0
See description of Parameter 475.
6 ZONE 3 PARAMETERS
6. 0 TEMPERATURE SETTINGS
6. 0. 0 Room Setpoint
(Comfort)
50 - 86 °F 66
Only applicable when using an NTI room sensor
6. 0. 1 Room Setpoint
(Reduced)
32 - 86 °F 61
Only applicable when using an NTI room sensor
6. 0. 2 Zone 3 Fixed Water
Temp
68 - 179 °F 179
6. 0 3 Room Setpoint (Holiday/
Anti-frost)
36 - 75 °F 41
Only applicable when using an NTI room sensor - Changes
all zones
6. 0. 5 CH Target temperature
logic
0 = Max active
zone target
1= Z1,Z2,Z3....etc.
2= Min active
zone taget
1
6. 1 AUTOMATIC WINTER MODE
6. 1. 0 Warm weather
shutdown
0 = OFF
1 = ON
0
6. 1. 1 WWSD threshold 50 - 86 °F 68
6. 1. 2 WWSD Switchoff delay 0 - 300 minutes 2
6. 2 ZONE 3 SETTINGS
6. 2. 1 AUTO Temperature
control MODE
0 = Fixed Outlet
1 =Basic On/Off
2 =Room Temp
3 =Outdoor Temp
4 =Room&Outdoor
3
6. 2. 2 Heating Curve Slope 0.2 - 3.5 1.3
See graph and description of Parameter 422.
6. 2. 3 Heating Curve Offset -25 - +25 0
See description of Parameter 423.
6. 2. 4 Room Sensor Influence 0 - 20 4
Adjusts the influence of room temperature on target
boiler temperature - a higher setting causes a greater
increase to the boiler target temperature as the indoor
temperature drops below room setpoint.
Only applicable when using an optional NTI Room
Sensor and when 6.2.1 = 2 or 4.
6. 2. 5 Max Temperature 68 95 - 179 °F 179
6.2.5 sets the allowable boiler operating temperature
range for Zone 3 heating, limiting Automatic Temperature
Control and manual adjustments from the User Menu.
6. 2. 6 Min Temperature 68 - 179 °F 95
6.2.6 sets the allowable boiler operating temperature
range for Zone 3 heating, limiting Automatic Temperature
Control and manual adjustments from the User Menu.
6. 2. 8 Quick night setback 0 = OFF
1 = ON
0
6. 2. 9 Heat request mode 0 = Standard
1 = RT time Programs
Exclusion
2 = Heat demands
forcing
1
6. 3 DIAGNOSTICS
6. 3. 0 Room Temperature Read only
Only applicable when using an NTI room sensor
6. 3. 1 Room Temperature
setpoint
50 - 86 °F Read only
Only applicable when using an NTI room sensor
6. 3. 4 Zone 3 Heat Call 0 = OFF
1 = ON (Read only)
5 3 8 Zone flow temperature
setpoint
Read only
6. 7 ZONE 3 REGULATION PARAMETERS
6. 7. 5 Auto Slope Boost 0 = OFF, 1 = ON 0
See description of Parameter 475.
7 EXTERNAL 3ZONE CONTROL MODULE
ONLY APPLICABLE WHEN USING THE NTI NLINK 3ZONE
CONTROL MODULE 3260184
7. 0
7. 0. 0 Heating setpoint offset logics
7. 0. 1 Cooling setpoint offset logics
7. 0. 2 Zone pumps in DHW cycle
7. 1 MANUAL MODE
7. 1. 0 ZM Manual mode activation
7. 1. 1 Zone 1 Output
7. 1. 2 Zone 2 Output
7. 1. 3 Zone 3 Output
7. 1. 4 Z2 Mix Valve Control
7. 1. 5 Z3 Mix Valve Control
7. 1. 6 Z1 Mix Valve Control
7. 2 GENERAL ZONE MODULE
7. 2. 0 Hydraulic scheme
definition
MCD
MGM II
MGM III
MGZ I
MGZ II
MGZ III
mix
2 direct
direct + mix
2 mix
3 direct zones
2 direct + mix
direct + 2 mix
3 mix
7. 2. 1 FlowT Offset
Menu
Sub-Menu
Parameter
Description Value
Default
Setting
Note
Menu
Sub-Menu
Parameter
Description Value
Default
Setting
Note
