TRX Series II - Installation - Startup - Maintenance Instructions
Part 9 - Controls
K. Diagnostic
Navigate the Diagnostics menu as follows:
1. From the Main Menu, turn the dial to
highlight “Diagnostics” and press ENTER.
2. Turn the dial to highlight the option you
wish to access then press ENTER.
3. Press ESC to return to the previous screen.
Technical Area
User Menu
Tech Menu
Test Mode
Error History
Diagnostics
Service
Statistics
Version
Diagnostics
Service
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Diagnostics
Service
Statistics
Diagnostics
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.1
Boiler pump on time (h/10)
xxx
xxx
xxx
xxx
xxx
Statistics
8.0.3 Boiler Power on time (h/10)
8.0.4
Fan on time (h/10)
Months to Next Maintenance
12
60
Maximum value
0
Minimum value
Enable Maintenance Warning
1
1
Maximum value
0
Minimum value
8.5.2 Maintenance Warning Reset
'Do you really want to perform the reset?
If you press OK button, the reset command
will be executed otherwise, by way of ESC,
the previous page is shown.
Version
Diagnostics
Service
Statistics
Diagnostics
Version
User Interfafce
Boiler
Remote Modem
Multi function clip slave
Diagnostics
Technical Area
User Menu
Tech Menu
Test Mode
Error History
Diagnostics
Service
Statistics
Version
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Diagnostics
Service
Statistics
Diagnostics
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.1
Boiler pump on time (h/10)
xxx
xxx
xxx
xxx
xxx
Statistics
8.0.3 Boiler Power on time (h/10)
8.0.4
Fan on time (h/10)
Months to Next Maintenance
12
60
Maximum value
0
Minimum value
Enable Maintenance Warning
1
1
Maximum value
0
Minimum value
8.5.2 Maintenance Warning Reset
'Do you really want to perform the reset?
If you press OK button, the reset command
will be executed otherwise, by way of ESC,
the previous page is shown.
Version
Diagnostics
Service
Statistics
Diagnostics
Version
User Interfafce
Boiler
Remote Modem
Multi function clip slave
Diagnostics
Technical Area
User Menu
Tech Menu
Test Mode
Error History
Diagnostics
Service
Statistics
Version
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Diagnostics
Service
Statistics
Diagnostics
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.1
Boiler pump on time (h/10)
xxx
xxx
xxx
xxx
xxx
Statistics
8.0.3 Boiler Power on time (h/10)
8.0.4
Fan on time (h/10)
Months to Next Maintenance
12
60
Maximum value
0
Minimum value
Enable Maintenance Warning
1
1
Maximum value
0
Minimum value
8.5.2 Maintenance Warning Reset
'Do you really want to perform the reset?
If you press OK button, the reset command
will be executed otherwise, by way of ESC,
the previous page is shown.
Version
Diagnostics
Service
Statistics
Diagnostics
Version
User Interfafce
Boiler
Remote Modem
Multi function clip slave
Diagnostics
Technical Area
User Menu
Tech Menu
Test Mode
Error History
Diagnostics
Service
Statistics
Version
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Diagnostics
Service
Statistics
Diagnostics
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.1
Boiler pump on time (h/10)
xxx
xxx
xxx
xxx
xxx
Statistics
8.0.3 Boiler Power on time (h/10)
8.0.4
Fan on time (h/10)
Months to Next Maintenance
12
60
Maximum value
0
Minimum value
Enable Maintenance Warning
1
1
Maximum value
0
Minimum value
8.5.2 Maintenance Warning Reset
'Do you really want to perform the reset?
If you press OK button, the reset command
will be executed otherwise, by way of ESC,
the previous page is shown.
Version
Diagnostics
Service
Statistics
Diagnostics
Version
User Interfafce
Boiler
Remote Modem
Multi function clip slave
Diagnostics
Technical Area
User Menu
Tech Menu
Test Mode
Error History
Diagnostics
Service
Statistics
Version
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Diagnostics
Service
Statistics
Diagnostics
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.1
Boiler pump on time (h/10)
xxx
xxx
xxx
xxx
xxx
Statistics
8.0.3 Boiler Power on time (h/10)
8.0.4
Fan on time (h/10)
Months to Next Maintenance
12
60
Maximum value
0
Minimum value
Enable Maintenance Warning
1
1
Maximum value
0
Minimum value
8.5.2 Maintenance Warning Reset
'Do you really want to perform the reset?
If you press OK button, the reset command
will be executed otherwise, by way of ESC,
the previous page is shown.
Version
Diagnostics
Service
Statistics
Diagnostics
Version
User Interfafce
Boiler
Remote Modem
Multi function clip slave
Diagnostics
Technical Area
User Menu
Tech Menu
Test Mode
Error History
Diagnostics
Service
Statistics
Version
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Months to Next Maintenance 12
Enable Maintenance Warning
Maintenance Warning Reset
Diagnostics
Diagnostics
Service
Statistics
Diagnostics
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.1
Boiler pump on time (h/10)
xxx
xxx
xxx
xxx
xxx
Statistics
8.0.3 Boiler Power on time (h/10)
8.0.4
Fan on time (h/10)
Months to Next Maintenance
12
60
Maximum value
0
Minimum value
Enable Maintenance Warning
1
1
Maximum value
0
Minimum value
8.5.2 Maintenance Warning Reset
'Do you really want to perform the reset?
If you press OK button, the reset command
will be executed otherwise, by way of ESC,
the previous page is shown.
Version
Diagnostics
Service
Statistics
Diagnostics
Version
User Interfafce
Boiler
Remote Modem
Multi function clip slave
Diagnostics
Table 42 - Main Menu - Diagnostic Menu
Figure 101 - Diagnostic Menu
Menu Option | Description (Range Default
SERVICE
Months to Next Maintenance (8.5.0)
Sets the number of months until a Maintenance Warning is triggered; number counts down over time.
Only applicable when Enable Maintenance Warning is set to On. Range = 0-24 months.
12
Enable Maintenance Warning (8.5.1)
When set to On, a Maintenance Warning will occur at a frequency set by Months to Next Maintenance.
OFF
Maintenance Warning Reset (8.5.2)
Press to reset the Months to Next Maintenance counter, i.e., after completing the scheduled maintenance of the appliance.
NA
STATISTICS
8.0.3
Boiler Power on time (h/10)
8.1.0
CH burner on time (h/10)
8.1.1
DHW burner on time (h/10)
8.0.4
Fan on time (h/10)
8.0.1
Boiler pump on time (h/10)
8.1.4
Average CH cycle time
8.1.6
CH/DHW priority switches
8.0.2
Boiler pump cycles (n/10)
8.0.0
DHW pump cycles (n/10)
8.0.5
Fan cycles (n/10)
8.1.3
Ignition cycles (n/10)
8.1.2
Flame Faults (n/10)
8.0.6
CH ame detection No. (n/10)
8.0.7
DHW ame detection No. (n/10)
VERSION
User Interface
NA
Boiler
NA
Remote Modem
NA
Multi function clip slave
NA
