5 - 52 en-938821/2
Actions
Select the Mode softkeys. ☞
MODE
Display of the Mode softkeys at the bottom of the screen:
SINGLE MDI DRYRUN SEARCH EDIT TEST MANUAL HOMEAUTO
Select the search mode. ☞
SEARCH
The search mode indicator is displayed in the status window (See 3.1.3).
Enter the coordinates of the sequence to be searched for (See syntax) ☞
Syntax (repeat as many times as there are axis groups)
N[block No.].[group No.] H[S/R No.]:[No. of times]
N[block No.] number of the block to be selected (belonging to the main program
or the specified subroutine), this term is mandatory
.[group No.] axis group number: this term must be specified for each of the axis
groups when using axis multigroups
H[S/R No.] subroutine number; this term is not used unless the block searched
for belongs to a subroutine
;[No. of times] number of times the block number is to be read before stopping the
search
Start the search by pressing the "CYCLE" button on the machine panel.
Display of the "INCYC" indicator in the status window (See 3.1.3).
Analysis of blocks from the start of the programme:
- values stored,
- coded M functions (list supplied by the OEM) sent to the PLC,
- decoded M functions (SeeA.1.2) and T functions (tools) sent to the PLC if allowed by the configuration (function
of parameter P7 defined by the OEM).
Stop on the block preceding the block to be found.
The "INCYC" indicator disappears.
Press the "CYCLE" button on the machine panel.
Display of the "INCYC" indicator in the status window (See 3.1.3).
Execution by the system of the auxiliary functions (decoded M functions, S and T functions) stored during the search.
The "INCYC" indicator disappears.
Display of the "CYHLD" and "AXRCL" indicators in the status window (See 3.1.3) if the axes are not in position.
