NUM 1040 M - Page 367

Use of Peripherals
en-938821/2 C - 9
C
C.1.2.2 TTL/Adapter Output Cables
Solder side
Solder side
1 2 43
10 cm
6
9
5
1
6
9
5
1
1 - 9-contact male Sub.D connector on the NUM side
2 - Shielded 6-wire cable (6x0.22 mm
2
), maximum length 1 m
3 - Wire and spade terminal for M3 screw (only for adapters at index A or B)
4 - 9-contact female Sub.D connector
CONNECTOR
BODY
PROTECTIVE
EARTH
CONNECTOR
BODY
PROTECTIVE
EARTH
DSR TTL
1
9
5 V
5 V
2
RD TTL
TD TTL
1
2
4
TD TTL
RD TTL
4
3
CTS TTL
RTS TTL
3
6
RTS TTL
or 0 V
CTS
TTL
6
DTR TTL
8
DCD TTL
7
5
0 V
0 V
5
4,7 kΩ 1/4 W
∗
4,7 kΩ 1/4 W
∗
∗ Resistors required for
cable lengths between
0.3 m and 1 m
ADAPTER
COVER
