233970 (Page 22) 10/11 (A13)
Machine Set-Up
ALWAYS ENSURE THAT THE BATTERY IS DISCONNECTED
BEFORE MAKING ANY ADJUSTMENTS
!
!
Fitting the brushes
Featuring the Nulock brush system.
Slide the brush / pad under the brush deck (Fig 6).
the brush / pad in place (Fig 7).
Only use manufacturer supplied brushes.
This machine requires a 400mm brush or a 360mm pad.
Fitting the Floor Tool
(Fig 8).
Secure to the carrier using the
Do not over tighten the retaining
knobs.
Fig 6
Fig 7
Fig 8
Fig 9
Fig 9a
Safety gloves are recommended for the changing of used brushes.
Note:
