Nuna Aace - Product Overview and Installation; Parts List; Vehicle Seat Belt Systems

EN EN
3635
Parts List
1 Head Support
2 Side Support
3 Seat Covers
4 Instructional Manual
(under seat)
5 Cup Holder
6 Seat Bottom
7 Armrest
8 Seat Back
9 Shoulder Belt Guides
10 Head Support Adjustment
Lever
11 Side Impact Protection (SIP)
Pod
12 Latch Connectors
13 Latch Release Lever
or Recline Lever (under seat)
14 Latch Guides
15 Shoulder Belt
Positioning Clip
instructions
1
2
3
4
5
14
15
6
7
8
9
10
11
12
13
1
2
3
Vehicle Seat Belt Systems
DO NOT install the booster on
vehicle seats with Lap Belts only.
(1)
DO NOT install the booster on
vehicle seats with lap belts and
motorized shoulder belts. (2)
DO NOT install the booster on
vehicle seats with belts that are
attached to the door or that move
along a track. (2, 3)
