Seat Adjustment for Head
Support and Shoulders
1 The Head Support height can
be adjusted for best t to your
child and proper placement of the
Vehicle Shoulder Belt.
Bottom of Head Support MUST be
even with the top of your child’s
shoulder.
2 To adjust, squeeze the Head
Support Adjustment Lever, then pull
up
(10) or push down (11) the
Head Support until it locks into one
of the nine positions as shown.
Before adjusting the Head Support
height have your child lean forward
slightly.
As the Head Support is adjusted up,
the sides of the seat automatically
move outward to provide more
shoulder room.
12
13
Seat Adjustment
for Seat Bottom
The seat bottom depth can be adjusted
for added comfort for the child. Three
positions are provided for best t.
1 Reach under the cover as shown to
adjust the seating surface in or out.
(12)
2 Slide the seating surface in or out
as needed for additional thigh
support. (12)
Use of Latch
Connectors
If vehicle is equipped with Latchs they
may be visable in the vehicle seat
where the vehicle seat back meets the
vehicle seat bottom. See your vehicle
owner’s manual for exact locations,
Latch identication, and requirements
for use.
1 To use the Latch Connectors, release
the connectors by pulling and
holding the Latch Release Lever on
the bottom of the booster seat as
shown in (13).
