Nuna PIPA rx User Manual

45PIPA rx instructions44 PIPA rx instructions
RELX
™
Base Installation Using
Rigid Latch (Lower Anchors)
(continued)
1
- Check installation by pulling on
the base AND seeing that green
is indicated on the connectors.
2 - The rigid latch must be
attached and locked onto the
vehicle anchor bars with the
indicator showing green. If
used, the stability leg indicator
must show green.
Retracted Positions
3 - There are three positions to
which the bottom of the base
retracts. In some vehicles, this
is necessary to allow the base to
sit against the vehicle seat back.
4 - If there is a gap between
the back of the base and the
vehicle seat after the rigid
latch lower anchors have been
attached, push on the top and/
or back of the base until it
touches the vehicle seat and a
“click” indicates it’s locked into
a retracted position.
A gap is acceptable if the base
clicks through all retracted
positions but is still not fully
against the vehicle seat.
(continued on the next page)
2
3
4
1 2 3
1

Nuna PIPA rx Specifications

General

Product Type	Infant Car Seat
Weight Capacity	4 to 32 lbs
Height Capacity	Up to 32 inches
Canopy	UPF 50+ canopy with flip out eyeshade
Harness	5-point harness
Base Compatibility	PIPA series base
Safety Features	Side impact protection
Safety Standards	FMVSS 213
Compatibility	Nuna strollers with adapters
Installation	Belt path or with base using True lock™ base installation
Weight of Car Seat	7.6 lbs (without base)
