Nuna revv User Manual

If using lap/shoulder belt (preferred installation method)
1 - Attach the tether hook loosely to the vehicle tether anchor. Pull the vehicle seat belt
across the anti-rebound panel and under the True Tension
™
door. If possible, secure
the vehicle lap belt under the belt positioner.
2 - With the lap belt portion routed under the True Tension
™
door and secured under the
second belt positioner, buckle the vehicle seat belt.
3 - Check the vehicle seat belt; make sure it is not twisted and is laying flat across the
anti-rebound panel. Remove any slack. Ensure the lap belt is routed under the door.
4 - Then while pushing down firmly on the car seat, pull up on the vehicle shoulder belt
to remove the slack. Pull the shoulder belt out all the way to switch the retractor. Now
when you release it, the belt will automatically lock when pulled (consult vehicle manual).
5 - Route the vehicle shoulder belt behind the anti-rebound panel and over tether strap.
6 - Close the True Tension
™
door (1). Tighten the tether by pulling on the tether
adjustment strap (2).
3
1
2
WARNING: Check that child restraint is securely installed before each use. Hold
seat at the belt path and move seat in all directions. Seat should move less than 1 inch.
PULL up on the SHOULDER BELT again to remove any slack.
44 REVV
™
instructions
45REVV
™
instructions
1
2
4 5 6

Nuna revv Specifications

General

Weight capacity	5 to 40 lbs (rear-facing); 25 to 40 lbs (forward-facing)
Orientation	Rear-facing and forward-facing
Recline positions	Multiple recline positions
Harness type	5-point harness
Type	Convertible car seat
Height Limit (Rear-Facing)	Up to 43 inches
Height Limit (Forward-Facing)	Up to 43 inches
Safety features	Energy-absorbing foam, side impact protection
Usage	Infant to toddler
