Fig. 1
KEY
1 Steam knob
2 Programming key (Vip Plus only)
3 LCD Display (Vip Plus only)
4 Functions buttons (Vip Plus only)
5 Selections buttons
6 Delivery unit buttons
7 Electronic displays
8 Steam knob
9 Filter-holder
10 Data plate
11 Manual steam nozzle
12 Delivery unit
13 Main switch
14 2 coffees spout
15 1 coffee spout
16 Automatic steam nozzle (optional in V and
ESSE version)
17 Optical level
18 Pressure Gauge
19 Adjustable foot
20 Manual steam nozzle
21 Hot water nozzle
22 Electric cup-warmer (steam cup-warmer,
optional)
19
18
17
15
10
9
8
11
13
1. DESCRIPTION Vip Plus - V - Esse
16 1214
1
2
4
63 75
21
20
22
