24
Specifi cations
Dimensions and Weight
• Length: 60” (152 cm)
• Width: 27” (69 cm)
• Height: 45” (115 cm)
• Weight: 210 lbs (95 kg)
User Height and
Weight Limits
• Height: 4’6” to 6’4” (137 cm
to 193 cm)
• Weight: 400 lbs (182 kg)
Overview
• Total body conditioning
of the cardiovascular and
muscular systems.
• Use arms alone, legs alone,
or both.
• Closed-kinetic chain
exercise.
• Low 7”–9” step-through
height for easy access.
• Biomechanically correct
workout position.
• Contralateral movement
– arm linked with opposite
leg.
• Smooth, fully connected
motion between arms and
legs.
• User-controlled step
length of 2”–8.5” (5-22
cm).
Resistance System
• Quiet, frictionless,
permanent magnetic eddy
current system with 10
workload levels.
• User power output from
5–800 watts.
• All-belt drive.
• Long-life, high-grade
bearings.
Frame
• Durable, heavy-duty
welded steel frame.
• Powder-coated frame and
zinc-plated components
resist rust.
• Four-point contact with
the fl oor and leveling feet
increase stability.
• Strong, impact-resistant
poly-styrene cover is easy
to clean.
• Anodized aluminum
arms with extra-long,
comfortable hand grips.
• Ergonomically correct
hand position.
• Long, 15” (38 cm) arm
adjustment range.
• Lift unit with front handle
and roll on rear wheels
or use optional NuStep
transporter device.
Seat and Arm Rests
• Swivel seat rotates
360
o
and locks at 45
o
increments
.
• Foam-covered seat and
swivel release levers work
from front, sides or back.
• Seat slides and adjusts
smoothly.
• 15” (38 cm) forward/
backward seat adjustment
range.
The maximum user
weight limit for this
product is 400 lbs (182
kg).
CAUTION
!
• Ergonomically designed
padded seat has
contoured back support.
Display
• Simple, one-button quick
start and reset; automatic
power on/off.
• Easy-to-read display
shows:
SPM: 5–210
Watts: 5–800
METS: 2–24
Time: Starts at 0:00,
counts up
Steps: Counts
cumulative
steps up to
9999
Distance: MI or Km
Load levels: 10 load levels
Calories: Up to 999 KCal
• User selects English or
metric measurement
system.
• Optional Polar
®
transmitter
belt enables heart rate
display on console.
• Cordless design uses 4 AA
alkaline batteries (NiMH
rechargeable batteries
may also be used).
• USB port for data
download.
Foot Pedals
• Pedals are made of
durable molded plastic.
• Four-bar linkage and
nonskid tread keep feet
secure.
For information about
optional accessories, please
visit our website,
nustep.com.
The T4r is very heavy;
it weighs 210 lbs (95
kg).
To avoid injury,
or damage to the
product, always obtain
assistance to move this
product.
Use proper lifting
technique.
CAUTION
!
To Next Page
