Preparation
Tools Needed Materials Needed
• 6" round metal ducting for PTE1115RK and PTEL1115RK models
• 4” round metal ducting for PTE511RK and PTEL511RK models
• Roof cap or wall cap (built-in damper recommended)
• Electrical wiring and supplies per local code requirements
Power screwdriver
with a Phillips bit
Phillips screwdriver
Flathead screwdriver
Pliers
Wire insulation stripper
Wire cutter
Foil tape
Safety glasses
Safety gloves
Fan Main Parts
Parts Bag Content
Mounting Frame
Housing
Blower
Muffler Plate
Trim Cover
Fan Lit Grille
Fan Only Grille
Controller
Power Box
6" Duct
Connector
4" Duct
Reducer
5 X Phillips Hex Head Screw
2 X Phillips Pan Head Screw
