NVE 4307 - Page 29

4307 & 4310 Blower | 29
4307 & 4310 Blower Complete | Parts List
ITEM QTY PART NUMBER DESCRIPTION
1 1 150-003-4310-1 ENDPLATE, DRIVE 4310 MACH
2 1 150-003-4310-2 ENDPLATE, NONDRIVE 4310 MACH
3 4 150-652-001 MOUNTING FOOT, 4310
4 4 150-630-747 SEAL SLEEVE, OD 4310/747
5 4 150-629-4310 SEAL SLEEVE, ID 4310
6 16 150 - 618-747 SEAL RING, 2.5 OD CAST IRON
7 4 1 50 - 6 31-747 SLINGER, SHAFT GUARD, 747
8 2 1 50 - 621-747 BEARING, 5309 (45 X 100 X 39.7)
9 4 150 -047-957 BEARING RETAINER, 957
10 2 1 50 - 622-747 BEARING, NU309 (45 X 100 X 25)
11 1 150-005-4307-D ROTOR, DRIVE 4307
11 1 150-005-4310-D ROTOR, DRIVE 4310
12 1 150-005-4307-I ROTOR, IDLER 4307
12 1 150-005-4310-I ROTOR, IDLER 4310
13 1 150-001-4307 HOUSING MAIN 4307
13 1 150-001-4310 HOUSING MAIN 4310
14 1 15 0 -64 5 -747 LOCK NUT DRIVE, ROTOR, 747
15 1 150 - 6 41-747 RETAINER, LOCKNUT 747
16 1 150 - 6 33 -747 SPACER, DRIVE END, FOLLOWER 747
17 1 1 50 - 613-747 TIMING GEAR, IDLER, 747
18 1 150-006-001 KEY, .375 SQ X 2" 1018 +.001/-.000
19 2 150 - 6 38 -747 RETAINER, IDLER ROTOR 747
20 1 150-61 2-747 TIMING GEAR, DRIVE, 747
21 1 150 - 63 6 -747 RETAINER, NONDRIVE END, 747
22 1 150-637-747 OIL SLINGER, NON-DRIVE END 747
23 1 150-624-747 B-LOC, RETAINING RING, FLANGED
24 1 150-635-747 OIL SLINGER, DRIVE END 747
25 1 1 50 - 0 09 -747 SEAL SLEEVE, OUTER
26 1 150 -627-747 END COVER, DRIVE END 4310
27 3 120 -047 DRAIN PLUG, 3/4" NPT
28 2 120-047-1 DRAIN PLUG, 3/4" NPT MAGNETIC
29 3 150-048 SIGHT EYE, 1 1/16"-12 SAE
30 1
150 -623 -747 BEARING, NU308 (40 X 90 X 23)
31 1 150-620-747 SEAL, 50 X 72 X 10 AS FMK
32 2 15 0 -639-747 GASKET, END COVER 747
33 1 15 0 - 628 -747 OIL COVER, NON-DRIVE 747/4310
36 1 802-650-009 BALLAST TEE W/ RISER, 4307 CAST
36 1 802-650-003A BALLAST TEE, 4310 CAST
