4.2 MONITOR MODE
The Monitor mode is invoked when you press the SHIFT key followed by the MONITOR key.
This mode allows you to test the heat tracing and examine any of the analog readings.
The data is updated in real-time, providing the user with a method of viewing tracer information
as it occurs.
4.2.1 MAIN MENU
Table 4.2 Monitor Mode Main Menu
C
ONTROL MODE = 4°C
T
S 1 TEMP = 4°C
T
S 2 TEMP = 7°C (only if TS2 is being used)
L
OAD = 8.9 A
R
ESIST = 13.26 Ω
G
FI = 0 mA
V
OLT = 118 V
P
OWER = 1050 W (or POWER = 10.4 kW)
T
EST TRACING = (Turn on tracing for 30 seconds)
D
ISPLAY TEST = (To abort DISPLAY TEST, press any key)
M
AINTENANCE DATA… = Note the “…” indicating a sub-menu
--- END ----
4.2.2 “MAINTENANCE DATA…” SUB-MENU
This sub-menu is used to view minimum and maximum temperatures, total accumulated
power, hours in use, and the number of hours since the last time the Controller was reset.
These parameters may be reset by the user.
Table 4.3 Maintenance Data Sub-Menu
MIN CTL TEMP = –2°C
M
AX CTL TEMP = 65°C
T
S 1 MIN TEMP = –2°C
T
S 1 MAX TEMP = 65°C
T
S 2 MIN TEMP = –1°C
T
S 2 MAX TEMP = 61°C
P
OWER ACCUM = 145.9 kW-h
C
ONTACTOR CYCLE COUNT = 1234 (only if Deadband or Prop. Amb. Contactor
modes are being used)
I
N USE = 2896 h
T
IME SINCE LAST RESET = 675 h
---- END ----
C
ONTROL TEMP = 4°C
T
S 1 TEMP = 4°C
T
S 2 TEMP = 7°C
L
OAD = 8.9 A
R
ESIST = 13.26 Ω
G
FI = 0 mA
V
OLT = 118 V
P
OWER = 1050 W
T
EST TRACING
D
ISPLAY TEST
M
AINTENANCE DATA…
---- END ----
