nVent.com | 7
It includes indicators for alarm and output status and an integral Operator Console. An internal
connector is provided to plug in an optional communications interface.
The Control Module packaging provides a rugged, vibration-proof design.
Temperature sensor, communications, and alarm control wiring are connected to the
lever-operated spring terminals, providing gas-tight, vibration-resistant connections.
A large, easy-to-read alphanumeric display and menu-driven interface eases controller
con- figuration and eliminates the need for an external programmer. Access is available for
all monitored parameters, programmed values, and alarm information. Enhanced security is
provided by password protection.
Single phase current monitoring, ground fault detection, and voltage monitoring are provided.
The nVent RAYCHEM 910 Control Module also incorporates a universal power supply, allowing
operation directly from 100 to 277 Vac.
1.4.2 COMMUNICATIONS INTERFACE
In applications where the user wishes remote configuration capability, or wants to
communicate trace information and/or alarms to another device such as a Group
Communications Controller (780 Series/GCC-9000), an optional communications interface
may be installed in the Control Module.
A modem version that maintains compatibility with legacy products is available, or other
industry-standard interfaces such as nVent RAYCHEM RS-232 and RS-485 may be specified.
1.5 CONTROLLER ASSEMBLIES
Two standard assemblies are available and stocked at the Factory:
1. An SSR version for use in ordinary or Class I, Division 2 areas
2. An EMR version for use in ordinary locations only
1.6 ORDERING AND CONFIGURATION GUIDE
NVENT RAYCHEM 910 CONTROLLERS – FACTORY INVENTORY
Description Catalog Number Part Number Weight
RAYCHEM 910 controller in an 8” x 10” FRP enclosure with
window. 2-pole 30 A EMR. Controls a single circuit with a
2-pole electromechanical relay.
(Approved for ordinary areas only)
910*E1FWL*EMR2 10170-001 15
RAYCHEM 910 controller in an 8” x 10” FRP enclosure with
window. 2-pole 30 A EMR. Controls a single circuit with a
2-pole electromechanical relay.
Includes an isolated 2-wire RS-485 communication option.
(Approved for ordinary areas only)
910*E1FWL*EMR2*485 10170-015 15
RAYCHEM 910 controller in an 8” x 10” FRP enclosure with
window. 2-pole 30 A 277 V SSR. Controls a single circuit with
a 2-pole solid-state relay.
(Approved for Class I, Div. 2 areas)
910*E1FWL*SSR2 10170-002 20
RAYCHEM 910 controller in an 8” x 10” FRP enclosure with
window. 2-pole 30 A 277 V SSR. Controls a single circuit with
a 2-pole solid-state relay. Includes an isolated 2-wire RS-485
communication option. (Approved for Class I, Div. 2 areas)
910*E1FWL*SSR2*485 10170-016 20
nVent RAYCHEM Supervisor Software RAYCHEM Supervisor 10391-002 1
RAYCHEM 910 CONTROLLERS – MADE-TO-ORDER (Contact factory for lead time)
