Pin# Pin Name Pin Definition Description
A7 TDO OUTPUT
A8 TMS NC Not connected
A9 3.3V POWER 3.3V power
A10 3.3V POWER 3.3V power
A11 PERST# OUTPUT PCIe Interface Reset#, drived by SoC
Key
A12 GND GND Ground
A13 REFCLK+ OUTPUT PCIe Reference Differential Clock. Not connected (default)
A14 REFCLK- OUTPUT PCIe Reference Differential Clock. Not connected (default)
A15 GND GND Ground
A16 PERP0 OUTPUT SoC TX
A17 PERN0 OUTPUT SoC TX
A18 GND GND Ground
A19 RSVD NC Not connected, option for SER_DO
A20 GND GND Ground
A21 PERP1 OUTPUT SoC TX
