Nvidia BlueField-2 BF2500 User Manual

29
Pin# Pin Name Pin Definition Description
A22 PERN1 OUTPUT SoC TX
A23 GND GND Ground
A24 GND GND Ground
A25 PERP2 OUTPUT SoC TX
A26 PERN2 OUTPUT SoC TX
A27 GND GND Ground
A28 GND GND Ground
A29 PERP3 OUTPUT SoC TX
A30 PERN3 OUTPUT SoC TX
A31 GND GND Ground
A32 RSVD NC Not connected, option for SER_CLK
A33 RSVD NC Not connected, option for SER_CAP
A34 GND GND Ground
A35 PERP4 OUTPUT SoC TX
A36 PERN4 OUTPUT SoC TX
A37 GND GND Ground

Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
