Nvidia BlueField-2 BF2500 User Manual

30
Pin# Pin Name Pin Definition Description
A38 GND GND Ground
A39 PERP5 OUTPUT SoC TX
A40 PERN5 OUTPUT SoC TX
A41 GND GND Ground
A42 GND GND Ground
A43 PERP6 OUTPUT SoC TX
A44 PERN6 OUTPUT SoC TX
A45 GND GND Ground
A46 GND GND Ground
A47 PERP7 OUTPUT SoC TX
A48 PERN7 OUTPUT SoC TX
A49 GND GND Ground
A50 RSVD NC Not connected
A51 GND GND Ground
A52 PERP8 OUTPUT SoC TX
A53 PERN8 OUTPUT SoC TX

Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
