Nvidia BlueField-2 BF2500 User Manual

31
Pin# Pin Name Pin Definition Description
A54 GND GND Ground
A55 GND GND Ground
A56 PERP9 OUTPUT SoC TX
A57 PERN9 OUTPUT SoC TX
A58 GND GND Ground
A59 GND GND Ground
A60 PERP10 OUTPUT SoC TX
A61 PERN10 OUTPUT SoC TX
A62 GND GND Ground
A63 GND GND Ground
A64 PERP11 OUTPUT SoC TX
A65 PERN11 OUTPUT SoC TX
A66 GND GND Ground
A67 GND GND Ground
A68 PERP12 OUTPUT SoC TX
A69 PERN12 OUTPUT SoC TX

Nvidia BlueField-2 BF2500 Specifications

General

Processor	ARM Cortex-A72
Memory	16 GB DDR4
Network Interfaces	2 x 100GbE
PCIe Interface	PCIe 4.0 x16
Product Type	DPU (Data Processing Unit)
Interface Type	Ethernet
Ethernet Ports	2
Maximum power consumption	75W
PCIe Lanes	16
Operating Temperature	0°C to 55°C
Storage Acceleration	Yes
Virtualization Support	Yes
Security Features	Secure Boot
