Nvidia DGX-2 SYSTEM User Manual

Introduction to the NVIDIA DGX-2 System
DGX-2 System User Guide
10
With EMI Shield Removed
ID
Qty
Description
1 2 NVIDIA NVLink™ plane card
1.2.8 Motherboard Tray Ports and Controls
ID
Qty
Description
1 1 (Optional) High profile PCI card slot (for network storage)
2 2 (Default) QSFP28 network ports (for network storage)
Left side port designation: enp134s0f0
Right side port designation:
enp134s0f1
3 1 RJ45 network port (for in-band management)
4 2 USB 3.0 ports
