Nvidia MSTFLINT Documentation

29
nv_debug_mode 0
nv_global_pci_conf 0
In order to include the nv_kdnet_data configuration in the template, change the 0 to 1,
asdemonstrated in the following example.
Example:
nv_kdnet_data 1

#mstconfig gen_xml_template /tmp/confs.txt /tmp/template.xml
Saving output...
Done!

#cat /tmp/template.xml
<?xml version="1.0" encoding="UTF-8"?>
<config xmlns="http://www.mellanox.com/config">
<nv_kdnet_data>

<!-- Legal Values: False/True -->
<kdnet_en></kdnet_en>

</nv_kdnet_data>
</config>
mstconfig xml2raw Command
The xml2raw command is an easy way to generate a flawless raw configuration file that can beused
in the set_raw command. The input for the command is an XML file that contains the dataof the
required configurations. To generate an XML file and fill it with the desired values, run
thecommands from Generating an XML Template for the Configurations, and then use the xml2raw
command to generate a raw file.
Example:
# cat /tmp/template.xml
<?xml version="1.0" encoding="UTF-8"?>
<config xmlns="http://www.mellanox.com/config">
<nv_kdnet_data>

<!-- Legal Values: False/True -->
<kdnet_en>True</kdnet_en>

</nv_kdnet_data>
</config>

#mstconfig xml2raw /tmp/template.xml /tmp/confs.raw
Saving output...
Done!

#cat /tmp/confs.raw
MLNX_RAW_TLV_FILE
0x03000004 0x00000085 0x00000000 0x80000000
mstconfig xml2bin Command
The xml2bin command is an easy way to generate a binary file that contains a binary dump
ofconfigurations. The input for the command is an XML file that contains the data of the
requiredconfigurations. To generate an XML file and fill it with the desired values, run the
commandsfrom Section 2.4.10, and then use the xml2bin command to generate a binary file.
Example:
#mstconfig xml2bin /tmp/template.xml /tmp/confs.bin
Saving output...
Done!
# hexdump -C /tmp/confs.bin
00000000 80 00 00 00 |....|
00000004
