# mstconfig -d 41:00.0 reset
Reset configuration for device 41:00.0? ? (y/n) [n] : y
Applying... Done!


-I- Please power-cycle device to load new configurations.
>mstconfig 41:00.0 query


Device 1:
----------
Device type: ConnectX-3
PCI Device: 41:00.0
Configurations: Next Boot
SRIOV_EN True(1)
NUM_OF_VFS 8
WOL_MAGIC_EN_P1 False(0)
WOL_MAGIC_EN_P2 False(0)
Using mstconfig
Using mstconifg with PCI Device in Bus Device Function (BDF) Format
Example:
# mstconfig -d 41:00.0

Device 1:
----------
Device type: ConnectX-3
PCI Device: 41:00.0
Configurations: Next Boot
SRIOV_EN True(1)
NUM_OF_VFS 16
WOL_MAGIC_EN_P1 False(0)
WOL_MAGIC_EN_P2 False(0)
Using mstconfig to Set VPI Parameters
In order to set VPI parameters through mstconfig, use the following command line:
# mstconfig -d <device> set [LINK_TYPE_P1=<link_type>] [LINK_TYPE_P2=<link_type>]
Example: Configuring both ports as InfiniBand:
# mstconfig 41:00.0 set LINK_TYPE_P1=1 LINK_TYPE_P2=1

Device #1:
----------
Device type: ConnectX3Pro
PCI device: 41:00.0
Configurations: Next Boot New
LINK_TYPE_P1 ETH(2) IB(1)
LINK_TYPE_P2 ETH(2) IB(1)

Apply new Configuration? ? (y/n) [n] : y
Applying... Done!
-I- Please reboot machine to load new configurations.
Using mstconfig to Set SR-IOV Parameters
In order to set SR-IOV parameters through mstconfig, use the following command line:
# mstconfig -d <device> set [SRIOV_EN=<0|1>] [NUM_OF_VFS=<NUM>]
Example: Turning on SR-IOV and enabling 8 Virtual Functions per Physical Function:
# mstconfig -d 41:00.0 set SRIOV_EN=1 NUM_OF_VFS=8

