--offset <offset> Specific page offset to read/write
--write <bytes> Perform write operation with specific data (list of
bytes, separated by ',')
--prbs_select <side> Module PRBS test mode side selector [MEDIA, HOST]
--prbs_mode <cmd> Perform PRBS test mode on the Module
[EN(Enable),DS(Disable)]
--
generator_p
attern
<pattern>
Set PRBS generator pattern
[PRBS31(default),PRBS23,PRBS7,PRBS11,PRBS9,PRBS13,
SSPR,SSPRQ]
--
swap_genera
tor
Enable PAM4 MSB <-> LSB generator swapping (Optional)
--
invert_gener
ator
Enable PRBS generator inversion (Optional)
--
generator_la
nes <lanes>
PRBS generator lanes to set (one or more lane
separated by comma)[0,1,2,3,4,5,6,7] (Optional -
Default all lanes)
--
checker_pat
tern
<pattern>
Set PRBS checker pattern
[PRBS31(default),PRBS23,PRBS7,PRBS11,PRBS9,PRBS13,
SSPR,SSPRQ]
--
swap_check
er
Enable PAM4 MSB <-> LSB checker swapping (Optional)
--
invert_check
er
Enable PRBS checker inversion (Optional)
--
checker_lan
es <lanes>
PRBS checker lanes to set (one or more lane separated
by comma)[0,1,2,3,4,5,6,7] (Optional - Default all
lanes)
--lane_rate
<rate>
Set PRBS checker and generator lane rate [HDR(50G)
(default),1.25G,SDR(2.5G),10.3125G,FDR(14G),EDR(25G
),NDR(100G)]
--show_diagnostic_info Show PRBS diagnostic counters information
--clear_diagnostic_info Clear PRBS diagnostic counters
--control_parameters Show Module Control Parameters
--tx_equalization
<value>
Set Module Tx Input Equalization in dB [NE(No
Equalization),1,2,3,4,5,6,7,8, 9,10,11,12]
--rx_emphasis <value> Set Module RX Output Emphasis in dB. for CMIS, pre-
emphasis value will be set [NE(No
Equalization),0.5,1,1.5,2,2.5,3,3.5,4,5,6,7]
--rx_post_emphasis
<value>
Set Module Rx Post Emphasis in dB [NE(No
Equalization),1,2,3,4,5,6,7]
