84
•
hw_version = 0x0

fw_version = 0x1063232c

--------------------------------------------------------------------------------

Segment - segment_command (0xfffa)

segment_header.segment_type = 0xfffa

segment_header.length_dw = 0x5

vhca_id = 0x0

segment_called = 0x2000

index1 = 0x21

index2 = 0x0

num_of_obj1 = 0x0

num_of_obj2 = 0x0

--------------------------------------------------------------------------------

Segment - segment_notice (0xfff9)

segment_header.segment_type = 0xfff9

segment_header.length_dw = 0xc

syndrome_id = 0x211

notice[0] = 0x2000

notice[1] = 0x21

notice[2] = 0x0

notice[3] = 0x0

notice[4] = 0x496e7661

notice[5] = 0x6c696420

notice[6] = 0x52657300

notice[7] = 0x0

notice msg = !Invalid Res

--------------------------------------------------------------------------------

Segment - segment_terminate (0xfffb)

segment_header.segment_type = 0xfffb

segment_header.length_dw = 0x1

--------------------------------------------------------------------------------
How to run parsing with ‘raw’ and ‘verbosity’ options:
# mstresourceparse --dump-file notice.txt --adb-file fw-4119-rel-16_23_2008.adb–raw-v

Notice - adb fw version 16.23.2008 is used for parsing while dump fw version is 16.99.9004

Parse 4 segments:

--------------------------------------------------------------------------------

Segment - segment_info (0xfffe)

segment_header.segment_type = 0xfffe

segment_header.length_dw = 0x4

dump_version = 0x0

hw_version = 0x0

fw_version = 0x1063232c

RAW DATA:

DWORD [0-3] :0x0004FFFE 0x00000000 0x00000000 0x1063232C

--------------------------------------------------------------------------------

Segment - segment_command (0xfffa)

segment_header.segment_type = 0xfffa

segment_header.length_dw = 0x5

vhca_id = 0x0

segment_called = 0x2000

