Model Family Ports
Maximum High Power
Support
SN5400
All 64 ports 12W
Ports
#1,5,9,13,17,21,25,29,33,37,4
1,45,49,53,57,61
21W
SN5600 with Dual 3KW PSU Port #1-64 18W
LED Notifications
The system’s LEDs are an important tool for hardware event notification and
troubleshooting.
LED Symbols
Symb
ol
Name Description Normal Conditions
System Status
LED
Shows the health of the
system.
Green/Flashing green when
booting
Fan Status LED Shows the health of the fans. Green
Power Supply
Units LEDs
Shows the health of the power
supply units.
Green
Unit Identifier
LED
Lights up on command
through the CLI.
Off or blue when activated
by the user
System Status LED
The LED in the red oval shows the system’s status.
Front (Ports Side):
