Interface Specifications
Small Form Factors Specifications
NVIDIA switch systems come in a flexible range of form factors - SFP/QSFP,
SFP28/QSFP28, SFP56/QSFP56, SFP-DD/QSFP-DD and OSFP.
All form factors specification documents are available on the Storage Networking
Industry Association (SNIA) Website.
USB Standard Specifications
For the specification documents of all available USB types, please refer to the document
library in the USB Organization Website.
RJ45 to DB9 Harness Pinout
In order to connect a host PC to the Console RJ45 port of the system, a RS232 harness
cable (DB9 to RJ45) is supplied.
RJ45 to DB9 Harness Pinout
