NVIDIA Spectrum-4 SN5000 2U Switch Systems Hardware User Manual 32
Port
Configuration
Physical
Connector
Subinterfac
e
Examples
2x400G
C1 s1 swp1s1, swp24s1
C2 s2 swp1s2, swp64s2
4x200G
C1 s1, s2 swp2s1, swp2s2
C2 s3, s4 swp8s3, swp8s4
8x100G
C1 s1, s2, s3, s4
swp60s1, swp60s2, swp60s3,
swp60s4
C2 s5, s6, s7, s8
swp55s5, swp55s6, swp55s7,
swp55s8
Initial Power On
Each system’s input voltage is specified in the Specifications chapter.
