28
e700 User Manual
TABLE 1
A/C V mode default settings
Connect the patient valve to the patient; the ventilator will
commence volume controlled A/C V ventilation with the default
parameters selected (as listed in Table 1) depending on the selected
patient size (Figure 07). The user can pause the ventilation by
pressing the Pause/Resume key (H) (Figure 01) and adjust the
parameters to the patient’s requirements before commencing
ventilation if necessary.
Infant Child Adult
AC/V SETTINGS
Rate (BPM) 30 15 10
Vt (ml) 100 250 500
Mv (L) (calculated values) 3.0 3.7 5.0
PEEP (cm H
2
O) 5 5 5
P max (cm H
2
O) 25 25 30
P min (cm H
2
O) 3 3 3
Mv max (L) 30 30 30
Mv min (L) 0.5 0.5 0.5
Ti (Sec.) 0.66 1.33 2.0
I:E 1:2 1:2 1:2
O
2
(%) 100% 100% 100%
PCV (cm H
2
O) - - -
F trig. (L/min) 3 3 3
