There could be multiple alarm/warning symbols visible on the
screen indicating multiple failures occurring at the same time. In
this case the visible and audible alarms will be based on highest
priority alarm.
All ventilation alarms of e700 are listed in the following Table-7.
TABLE 7 - Ventilation Alarms and Symbols
Symbol Name Priority
Visual Alarm
Audible
Alarm
Alarm Symbol Warning LED
Patient Circuit
disconnect
(Breathing
circuit Integrity)
High after
15 seconds
Flashing Symbol
Flashing yellow
for 15 seconds,
then red
15 sec. delay
Two bursts with
fi ve pulses
LOW PAW
Low Airway
Pressure
High Flashing Symbol Red
Two bursts with
fi ve pulses
HIGH PAW
High Airway
Pressure
High Flashing Symbol Red
Two bursts with
fi ve pulses
LowMv
Low minute
Volume
High Flashing Symbol Red
Two bursts with
fi ve pulses
HighMv
High Minute
Volume
High Flashing Symbol Red
Two bursts with
fi ve pulses
Blocked
Airway
Blocked airway High Flashing Symbol Red
Two bursts with
fi ve pulses
Leak (at 40%
below set Vt)
High Flashing Symbol Red
Two bursts with
fi ve pulses
LowPi
Low Inhalation
Pressure
High Flashing Symbol Red
Two bursts with
fi ve pulses
No Oxygen
≤ 20 PSI
High Flashing Symbol Red
Two bursts with
fi ve pulses
Low Oxygen
≤ 40 PSI
Medium Flashing Symbol Yellow
One burst
with 3 pulses
