OMC-160-3 Manual Page 12
4.6.2 Alignment LED’s
Table 2: Upper LED’s on juntionbox PCB
On
+
Direction within 1 – 5 degrees
N
Direction is 0 degrees
-
Direction within 355 - 359 degrees
4.6.3 Status LED’s
Table 3: Lower LED’s on juntionbox PCB
On
Off
S
Speed sensor OK
Speed sensor fault
D
Direction Sensor OK
Direction sensor fault
O
Flashes at NMEA output rate
No NMEA output
