11
Sauna Heater Manual
7. Installation
Conrm the model you have selected is suitable for your sauna room, please refer to the table
below.
i. Ensure the power supply is suitable for the sauna heater
ii. Isolate the power supply before installation. The sauna heater will be controlled via the
iii. The installation position must comply with the minimum distance in the table below and in
the diagrams on the following page
iv. The minimum height of your sauna room must be 1900mm, please refer diagrams on
following page
v. Do not install the sauna heater on the oor or in a cabinet
vi. Do not cover the sauna heater back with asbestos cement or similar material
vii. The wire which enters the sauna room must be type 60245 IEC 66 HO7RN-F (BSEN 6141) please
refer to table below
viii. Do not install two or more sauna heaters in one sauna room.
ix. The sauna heater becomes very hot when operating and must be guarded to protect incase of
accidental contact, please see the sizes in g D and also refer to charts below and on following
page
x. The upper supporting screws must be xed tightly, there is a 3mm gap between the screw
head and wall (refer g A, g B), additional retaining screws should be inserted into the round
holes to prevent the heater being lifted.
xi. The stauna controller can be mounted inside or outside of the cabin using the wiring panel
provided.
xii. The controller should be kept at a height of between 1200MM-1500MM so that it is easily
controlled and operated
xiii. Temperature sensors should be installed in sauna room but not directly above sauna heater,
the height should be 1500-1800mm from oor. The horizontal distance to sauna heater should
exceed 500mm
Model Sauna Room Min Distance from Sauna
(mm)
Current (A) Fuse (A)
Volume (m
3
) Min
height
Distance to shelf
over 500mm
above the oor
Ceiling Floor 230V
1N~
400V
3N~
230v
1N~
400V
3N~
Min Max
0CS30 2 4 1900 50 1100 180 16 / 20 /
0CS40 3 5 1900 50 1100 180 20 10 25 /
OCS45 4 6 1900 80 1100 180 20 10 25 10
OCS60 5 8 1900 150 1100 180 32 16 40 16
OCS80 7 11 1900 200 1100 180 45 16 60 20
OCS90 8 12 1900 200 1100 180 45 20 60 20
