6 System Connections
• Do not connect the power cord until all other connections have been made.
• Each time you restart the unit, it remembers the last function used.
• Please make all the connections before installing the unit in the kitchen.
6.1 Connecting To External AV Signal Source
Connections should be made as follows:
Connect the L/R audio cables according to the marks on the rear panel of the unit: Left
audio cable is plugged into the upper jack; the right audio cable is plugged into the lower
jack.
6.2 Connecting To TV Signal Input Source
Connect the cable of the TV signal source in the 75 Ohm ANT input on the rear panel of
the unit.
TV Signal Input
