ODYS MultiFlat MF 700 DVB-T
17
EN
6.5 Connecting to DVB-T Antenna
The unit is designed with an antenna input jack. Plug the DVB-T antenna into the DVB-T
jack on the rear panel of the unit to receive TV signal, then press DVB-T button on the
remote control to switch to the DVB-T mode, as shown below (see chap. 6.9).
6.6 Installing the Unit
Note
Before installing the unit in the kitchen, please make all the connection.
Installing the unit under a cabinet
The player unit may be installed in the kitchen with or without the spacer. The suggested
mounting position of the unit is under a wall cabinet. See drawings below.
Quick hints
• Since the unit is rather heavy, be careful while doing the installation work.
• To reduce risk of fire, do not place any heating or cooking appliance beneath the unit,
especially while the LCD screen is open for viewing.
DVB-T Signal Input
To Next Page
