OEC COMPACT 7600 Series - Page 13

F2
2A
F1
2A
0VAC
90VAC
W1
W3
24
15
10
13
11
+24V +16V
+5V
+16VS
+5VS
S13
R39
NG1 POWER SUPPLY
Supplies power for:
- Control Rack/Generator
- Camera
- II
Page 2 of 3
For Reference Only
POWER ON
03/11/97
POWON_S.DS4
SERIES 7600
K2
R1
T1
F4
10A
24VAC
R3
C1
70mS
Delay
B79 BOARD
X2
13
90VAC
All relays shown
in the de-energized
state
F3
2A
BR1
24VDC
0
24
24
POWER ON
1. Relays K1 on both the C-arm and Workstation B111 boards energize
when either the C-arm or Workstation "On Switch" is pressed.
2. Power relay K1 in the C-arm and power relay K3 in the Workstation
then energize allowing AC power to the C-arm T1 and Workstation T1.
The initial input current is limited by R1 in both the C-arm and Workstation.
3. Approximately 70ms later the power relays K2 in both the C-arm and
Workstation energize, allowing the input current to bypass the current
limit resistor R1.
POWER OFF
1. Relays K1 on both the C-arm and Workstation B111 boards de-energize
when either the C-arm or Workstation "Off Switch" is pressed.
2. Power relay K1 in the C-arm and power relay K3 in the Workstation then
de-energize shutting off AC power to both the C-arm and Workstation
T1 transformers.
Workstation
C-Arm
K2
R1
F4
2A
F3
6.3A
T1
HARD COPY
PRINTER
F1
100mA
Supplies power for:
- B104
- Monitor Rotation
- X-RAY LAMP
4
1
3
+5V
2 5
24VAC
6
+5V
F2 + F3 F4 + F5
F5
315 mA
B 116
POWER SUPPLY
315 mA
315 mA
110 VAC
230 VAC
A
B
C
D
1
1
1
= Chassis GND
= Isolated GND
GND NOTE:
NOTES:
LEFT VIDEO
MONITOR
F1/F2
2.5A
RIGHT VIDEO
MONITOR
F1/F2
2.5A
CPU-100
NWA-500
BSA-5 00C
BSA-5 00
BMS-100 FRAME STORE
S2
S3
S4
Serial
Port
Parallel
Port
Not
Used
6
11
3
1
V4
V3
V2
V1
NWA-500
V4
V3
V2
V1
IN
OUT
AC IN
FUSE
I/0
F1/F2
4A
Multiformat
Camera
(1 on 1) or (2 on 1)
F1/F2
500mA
See page 3 for transformer wiring
X3
X1
F3/F4 100mA
B117 PWR SUPPLY
Supplies power for B108
+5
+5
+12
8
F1
1.6A
F5
800mA
F2
500mA
6
1
5
220
VAC
ST2
