EN-2 Ethernet Interface
SETUP
Upon installation, the scale will recognize the Ethernet Interface Kit.
PRINT2 Ethernet
Reset IP Addr
Stable Only End
Off, On
A.Print
Off, On.stbl,
Int, cont, Acc
Content
Layout
Data.Tr
End
*Note: Print and Ethernet menu selections may vary between the different scale series.
Setup Definitions
PRINT / Stable Only - On Transmits stable data only
PRINT / A.Print – On.Stbl Automatically outputs data upon stability
PRINT / A.Print – On.Acc Automatically outputs data in Accept Range
PRINT / A.Print – Cont Repeatedly sends data as fast as possible
PRINT / A.Print – (xx) SEC Sends data every (xx) seconds
PRINT / A.Print – OFF Sends data when PRINT is pressed or P command
PRINT / Data.Tr – On Transmits data
E.t.h.r.n.t / Ip Adr Displays the scales IP Address
Ethernet Connection
The Interface has a preset IP Address which can be displayed by choosing Ip Adr in the menu. Use
the “No” and “Back” keys to show the entire number on the display. The Port Number is 9761.
OPERATION
Output
With the interface installed the scale will operate in one of the following two ways:
Auto Print = off, Stable = on or off
Pressing PRINT will send the display data. If Stable is set to On, the balance will wait for a
stable reading before sending data.
Auto Print = not off, Stable = on or off
The scale will automatically send data based on the settings in the Menu. If Stable is set to On,
only stable will be sent.
Data sent is in standard ASCII format terminated with a [CRLF] (carriage return-line feed).
[weight] 9 characters
[space] 1 character
[unit] 5 characters max (left justified)
[space] 1 character
[stability indicator] 1 character “?” when unstable, blank when stable
[G/N] 1 character
[LF] 1 character
