5/Disassembly and Repair
Install the tubing for the hydraulic system in parallel
and make sure it does not overlap until it reaches the
storage area. The tubing must not be stretched, pinched
or kinked during reassembly.
ZZ
É
Lu
x o
La
Figure 5-14
Hydraulic Tubing Installation
5-15
