INSTRUCTIONS OJ-DV | General
Safety
• In accordance with EN 61800-5-1 – Adjustable speed electrical power drive systems. Part 5.
Safety requirements – Electrical, thermal and energy.
EMC - Electromagnetic compatibility
Table 8.1
OJ-DV size Motor cable length Intended use PDS of category
EN-61800-3
Immunity Emission
0.55…..1.3 kW <5.0 m First environment C1 & C2 EN-61000-6-2 EN-61000-6-3
1.5…..3.0 kW <5.0 m First environment C1 & C2 EN-61000-6-2 EN-61000-6-3
4.0…..7.5 kW <5.0 m First environment C1 & C2 EN-61000-6-2 EN-61000-6-3
11.0 kW <5.0 m First environment C1 & C2 EN-61000-6-2 EN-61000-6-3
15.0 kW <4.0 m First environment C1 & C2 EN-61000-6-2 EN-61000-6-3
11.0…..15.0k W >4.0 Second environment C3 EN-61000-6-2 EN-61000-6-4
• In accordance with EN 61800-3 – Adjustable speed electrical power drive systems. Part 3. EMC
requirements and specific test methods. See table 8.1
• The OJ-DV product line fulfils the “residential level” for emissions as per EN-61000-6-3 and the
“industrial level” for immunity as per EN-61000-6-2 with up to 5 metre shielded motor cables.
(15kW is limited to up to 4 metre motor cables).
• Longer motor cables can be used. Industrial level for both immunity and emissions can be fulfilled,
depending on the cable capacity as well as the motor capacity.
By reducing the motor cable length, it is possible to install up to 6 OJ-DVs in the same unit with EN-61800-
3 C1 & C2 still being fulfilled.
RoHS compatible
• Contains no hazardous substances according to the RoHS Directive.
9. Product programme
• OJ-DV is available in four dierent enclosures, whose size depends on the rated power of the
OJ-DV.
• The product programme contains 12 power sizes ranging from 0.55 kW to 15.0 kW, see table 9.
• Enclosures are designated ”H1”…”H5”, where ”H1” is the smallest and ”H5” is the largest.
• All enclosures are made of die-cast aluminium.
Table 9
Product name Enclosure Power Supply voltage Dimensions (w, h, d)
OJ-DV-1005 H1 0.55 kW 1 x 230 V 185 x 230.5 x 90 mm
OJ-DV-1007 H1 0.75 kW 1 x 230 V 185 x 230.5 x 90 mm
OJ-DV-1011 H1 1.1 kW 1 x 230 V 185 x 230.5 x 90 mm
OJ-DV-1013 H1x 1.3 kW 1 x 230 V 185 x 265 x 125 mm
OJ-DV-3016 H3 1.6 kW 3 x 400 V 185 x 265 x 100 mm
OJ-DV-3024 H3 2.4 kW 3 x 400 V 185 x 265 x 100 mm
OJ-DV-3030 H3 3.0 kW 3 x 400 V 185 x 265 x 100 mm
OJ-DV-3040 H4 4.0 kW 3 x 400 V 220 x 294 x 107 mm
OJ-DV-3055 H4 5.5 kW 3 x 400 V 220 x 294 x 107 mm
OJ-DV-3065 H4 6.5 kW 3 x 400 V 220 x 294 x 107 mm
OJ-DV-3075 H4 7.5 kW 3 x 400 V 220 x 294 x 107 mm
OJ-DV-3110 H5 11.0 kW 3 x 400 V 244 x 399 x 144 mm
OJ-DV-3150 H5 15.0 kW 3 x 400 V 244 x 399 x 144 mm
All 3x400V versions can also be connected to 3x230V. The power output (kW) will, however, be limited to
max. 58% (1/√3) of the rated power output at 3x400V.
