Oki B401dn User Manual

Paper recommendations > 35
> Envelopes should be loaded flap down, face up with the top edge to the left and
short edge into the printer.
> Load Transparencies face up and top edge into the printer.
> For heavyweight paper or cardstock open the rear stacker to collect the printed
output. This will give the paper a nearly straight path through the machine,
avoiding paper jams and damage to the paper.
3. B431: If required, set the media size and orientation in the media menu using the
control panel, then issue the print command.
B401/B411: If required, set the media size and orientation in the Configuration
Tool, then issue the print command.
P APER FEED , SIZE AND MEDIA SETTING
The process used to fuse (fix) the printed image to the paper involves a mixture of pressure
and heat. Too much heat will cause lightweight paper to crease or curl and corrugations in
transparencies. Too little heat will cause the image not to fuse fully into heavyweight paper.
B401 DN , B411 D , B411 DN
You can change the media type as follows:
1. Start the Configuration Tool.
2. Expand the User Menu to list the options.
3. Expand the Media Menu to list the options.
4. Click on the paper tray being used. Adjust the media type to the required setting
and, if necessary, the paper size to the size of the paper being used.
5. Click Save to Device icon, to save the new settings.
6. Click OK.
NOTE
Do not select Duplex printing on envelopes.
CAUTION!
Damage to the printer may occur if the incorrect paper setting is
used when printing on a different media.
NOTE
> You can also set the media type in your printer driver. However, the
printer driver settings will override the settings on the control panel or
Configuration Tool.
> Remember to reset the printer for normal paper after printing on a
different media.
NOTE
Although media properties can be set in the printer driver for particular jobs,
when filling a tray with media it is recommended that you manually set the
printer to match the media as described here.

Oki B401dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
PCL fonts	87
Bitmap fonts	OCR-A, OCR-B
Printer fonts	Bitmap, PCL
Maximum duty cycle	30000 pages per month
Recommended duty cycle	2000 pages per month
Number of print cartridges	-
Page description languages	Epson FX, IBM ProPrinter, PCL 5e, PCL 6
Processor family	PowerPC
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Product color	White
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	70 W
Power consumption (printing)	510 W
Power consumption (PowerSave)	7 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Compatible operating systems	Windows XP (32-bit & 64-bit) / Server 2003 (32-bit & 64-bit) / Vista (32-bit & 64-bit) / Server 2008 (32-bit & 64-bit) / Server 2008 R2 (64-bit) / 7 (32-bit & 64-bit); Mac OS X Intel 10.4-10.7
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	387 x 364 x 244.5 mm
