Oki B401dn User Manual

2-sided printing > 50
2- SIDED PRINTING
The duplex unit adds the function of two-sided printing, using less paper and making large
documents easier to handle. It also enables booklet printing, which uses even less paper.
You can print using Auto Duplex or Manual Duplex function.
A UTO DUPLEX PRINTING
This printer provides automatic two-sided printing only for Letter, A4, B5, Executive Legal
13, 13.5 and 14, using paper stocks from 60 - 122g/m².
To carry out Auto Duplex Printing:
1. Select File > Print and click the Properties button.
2. Select the input tray (Tray1, Tray2 (optional B411d, B411dn, B431d, B431dn), Multi
Purpose Tray (B431d, B431dn) or Manual Feed Tray (B401dn, B411d, B411dn))
from the Source drop down.
3. In the Duplex printing drop down menu, select either Long Edge (Auto) or Short
Edge (Auto) according to your printing preferences.
4. If you require further information, click the Duplex Help button.
5. Click the Print button.
M ANUAL DUPLEX PRINTING USING THE PAPER TRAY (W INDOWS ONLY )
To carry out 2-sided, or Manual Duplex Printing you must pass paper through the printer
twice. You can carry out 2-sided printing using the Paper Tray or the Manual Feed Tray
(B401dn, B411d, B411dn) or the Multi Purpose Tray (B431d, B431dn). You can use A4, A5,
A6, B5, Letter, Legal 13, 13.5 and 14, Statement, Executive and Custom paper sizes, using
paper stocks from 60 - 122g/m².
1. Ensure that there is enough paper in the Paper Tray to carry out the print job.
2. Select File > Print and click the Properties button.
3. Select Tray1 from the Source drop down.
NOTE
The steps in the process relate to Windows XP PCL. Other operating system
windows may appear slightly different, but the principles are the same.
NOTE
Manual Duplex printing is available only for Windows PCL Driver.
NOTE
> You cannot use A6 paper size for printing from Tray 2 (option).
> You can print on Legal 13.5 paper only from Tray1, optional Tray2 and
when using Auto Duplex function.

Oki B401dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
PCL fonts	87
Bitmap fonts	OCR-A, OCR-B
Printer fonts	Bitmap, PCL
Maximum duty cycle	30000 pages per month
Recommended duty cycle	2000 pages per month
Number of print cartridges	-
Page description languages	Epson FX, IBM ProPrinter, PCL 5e, PCL 6
Processor family	PowerPC
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Product color	White
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	70 W
Power consumption (printing)	510 W
Power consumption (PowerSave)	7 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Compatible operating systems	Windows XP (32-bit & 64-bit) / Server 2003 (32-bit & 64-bit) / Vista (32-bit & 64-bit) / Server 2008 (32-bit & 64-bit) / Server 2008 R2 (64-bit) / 7 (32-bit & 64-bit); Mac OS X Intel 10.4-10.7
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	387 x 364 x 244.5 mm
